    Solderless Led Lamp Beads AC COB 80W Integrated Projection Light Chip

    Ask Lasest Price
    Brand Name : newspectrum
    Model Number : NEW 5080
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100000pcs/day
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Solderless Led Lamp Beads AC COB 80W Integrated Projection Light Chip

    Solderless AC COB 80W driver free COB light source LED bead linear light engine integrated projection light chip

    model
    HZZM5080-110V-80W
    Overall dimensions
    50 * 80 (mm)
    Luminous surface size
    25 * 25 (mm)
    power
    80 (W)
    Color rendering index
    70-80
    Luminous flux
    8000 (lm)
    Forward voltage
    120 (V)
    Reverse voltage
    120 (V)
    Electrostatic breakdown voltage (ESD)
    2000 (V)
    Rated current
    0.67 (A)
    Chip brand
    San An
    Chip size
    2235 (mil)
    Fluorescent powder brand
    brill
    Glue brand
    Shinyue, Japan
    Wire material
    nothing
    Substrate material
    Superconducting aluminum
    Luminous angle
    120 °
    luminous efficiency
    100 (lm/W)
    Color tolerance
    5 (SDCN)
    thermal resistance
    ≤ 10 (°/W)
    Maximum allowable junction temperature
    120 °
    Voltage temperature coefficient
    60 (mV/° C)
    1000 hours of routine aging
    103%
    6000 hours of routine aging
    100%
    Did you pass the LM-80 test
    no
    Color temperature range
    3000-6500 (K)
