    DC Inverted Integrated COB LED Module 20W 30W High Power LED

    Ask Lasest Price
    Brand Name : newspectrum
    Model Number : COB4046
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 3-5 workdays
    • Product Details
    • Company Profile

    DC Inverted Integrated COB LED Module 20W 30W High Power LED

    DC Inverted Integrated Cob Light Source Cob4046 Beads 20W/30W/50W Floodlight Street Lamp High Power LED

    Article number
    COB4046-CW/WW/PK
    model
    COL-4046
    Overall dimensions
    40 * 46 (mm)
    Luminous surface size
    25 * 25 (mm)
    power
    50 (W)
    Color rendering index
    ≥ 70
    Luminous flux
    5000 (lm)
    Forward voltage
    30 (V)
    Reverse voltage
    30 (V)
    Electrostatic breakdown voltage (ESD)
    2000 (V)
    Rated current
    1.5 (A)
    Chip brand
    San An
    Fluorescent powder brand
    brill
    Glue brand
    Shinyue, Japan
    Wire material
    No gold thread
    Substrate material
    High conductivity aluminum substrate
    Luminous angle
    120 °
    luminous efficiency
    100 (lm/W)
    Color tolerance
    5 (SDCN)
    thermal resistance
    ≤ 5 (°/W)
    Maximum allowable junction temperature
    120 °
    Voltage temperature coefficient
    250 (mV/° C)
    1000 hours of routine aging
    101%
    6000 hours of routine aging
    98%
    Did you pass the LM-80 test
    no
    Color temperature range
    1400-6500 (K)
